Fire-Lite IPDACT-2 - Manual (Page 41)

IPDACT-2(UD) - Configuration
III-38
Doc.DM385-I
Rev. 4.0
If the process has successfully completed, an OK will appear on the console.
If however there has been as error, this could be either:
‰ “VA unreachable”: It has not been possible to send the register
command over the IP network.
‰ “No answer”: The register command has been sent but a response
has not been received from the VisorALARM.
‰ “Error on answer”: The answer from the VisorALARM for the register
command is wrong.
The following figure displays the default values. Press z to return to the
previous menu.
-- Quick Install --
a) DHCP client: OFF
b) IP addr: 172.24.77.250 mask: 255.255.0.0
c) Gateway IP: 172.24.0.98
d) Account Number: 9005
e) Supervisory Main: 80.26.96.183
f) Supervisory Backup: 80.36.189.123
g) Maintenance: 172.24.77.57
h) Port: 1222
i) Register MIP
j) Reset
k) Autoregister MIP:
z) Exit
option:
III - 4.6. Monitoring
The rest of the options permit you to inspect the distinct IPDACT-2(UD)
aspects and to monitor the state and view the enabled events. In order to exit
each option, press any key which will return you to the main menu.
Option e) displays the IPDACT-2(UD) general parameters, such as the serial
number, firmware release, etc.
