Fire-Lite B350LP Plug-In Base for Addressable Detector User Manual
Page 4
REMOTE ANNUNCIATOR, MODEL RA400Z
Connect the remote annunciator between terminals 1 and 3 using the spade lug terminal included. The spade lug termi-
nal is connected to the base terminal as shown in Figure 5.
It is not acceptable for three stripped wires to be under the same wiring terminal unless they are separated by a washer
or a lug like the spade lug supplied with the model RA400Z. See Figure 5 for installation.
A78-1473-00
Figure 5. Connection to Remote Annunciator Terminal.
STRIPPED WIRE
WIRE WITH
SPADE LUG
F400-21-00
4
I56-954-01R
©2000 Fire•Lite
Please refer to insert for the Limitations of Fire Alarm Systems
