CHECKLIST AND SERVICE INFORMATION

IMPORTANT

The installer may be able to observe and correct certain problems which

might arise when the unit is put into operation or when it is re-fired after a

prolonged shutdown. HOWEVER, it is recommended that only qualified

servicemen, using appropriate test equipment, be allowed to service the

heater.

BE SURE TO TURN OFF THE ELECTRICITY WHENEVER POSSIBLE OR

APPROPRIATE WHILE CHECKING EQUIPMENT.

WARNING

FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN SERIOUS

PERSONAL INJURY OR DEATH.

CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN

SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND

DANGEROUS OPERATION.

VERIFY PROPER OPERATION AFTER SERVICING.

BURNER OPERATIONAL PROBLEMS

1. Refer to TROUBLESHOOTING.

NOT ENOUGH OR NO HOT WATER

1. Be certain the electrical disconnect switch serving the water heater

is in the ON position.

2. Check the fuses.

• The electrical disconnect switch usually contains fuses.

3. The capacity of the heater may have been exceeded by a large

demand for hot water.

• Large demands require a recovery period to restore water

temperature.

4. Colder incoming water temperature will lengthen the time required to

heat water to the desired temperature.

• If the heater was installed when incoming water temperature was

warm, colder water creates the effect of less hot water.

5. Look for hot water wastage and leaking or open hot water faucets.

6. Sediment or lime scale may be affecting water heater operation.

Refer to MAINTENANCE for details.

7. The heater’s temperature high limit sensor has activated. Press the

reset button on the thermostat.

8. Burner may not be firing at proper rate.

• Check gas pressure. Adjust to obtain required manifold pressure.

9. Burner fan wheel may be dirty.

• Clean fan wheel with a stiff brush.

10. Condensate hose may be blocked where it connects to the exhaust

elbow.

• Verify the condensate drains from the unit without restriction.

WATER IS TOO HOT

1. Refer to WATER TEMPERATURE CONTROL.

WATER HEATER MAKES SOUNDS

1. Sediment or lime scale accumulations cause rumbling and pounding

noises when the heater is operating.

• The sounds are normal, however, the tank bottom should be cleaned.

Refer to MAINTENANCE for details.

2. Some of the electrical components of the water heater make sounds

which are normal.

• Contacts click or snap as the heater starts and stops.

• Transformers often hum.

WATER LEAKAGE IS SUSPECTED

1. Check to see if the water heater drain valve is tightly closed. Also

check the cleanout opening for leakage.

2. The apparent leakage may be condensation which forms on cool

surfaces of the heater and piping.

3. If the outlet of the relief valve is leaking it may represent:

• Excessive water pressure.

• Excessive water temperature.

• Faulty relief valve.

Excessive water pressure is the most common cause of relief valve

leakage. It is often caused by a “closed system”. If a check valve is in the

inlet system it will not permit the expanded hot water volume to equalize

pressure with the main. The relief valve must release this water or the

water heater or plumbing system will be damage d. Refer to MAINTENANCE-

RELIEF VALVE section in this manual.

When such a condition is encountered, local codes or inspection agency

should be consulted to determine which system is acceptable in your area.

See CLOSED SYSTEM section in this manual also.

TROUBLE-SHOOTING

WARNING

JUMPING OUT COMPONENTS AND/OR CIRCUITS DURING

TROUBLESHOOTING CAN CAUSE SERIOUS PROBLEMS WITH THE UNIT’S

OPERATING SEQUENCE AND IGNITION SAFETY. IF YOU DO NOT HAVE

THE PROPER TEST EQUIPMENT, I.E. A VOLT-OHM METER AND A

MICROAMMETER, DO NOT ATTEMPT TO TROUBLESHOOT OR REPAIR A.O.

SMITH EQUIPMENT.

ALTERING THE CONTROLLER AND/OR CONTROLLER WIRING IN ANY WAY

COULD RESULT IN INTERNAL DAMAGE TO THE MODULE CIRCUITS,

POSSIBLY ALTERING THE IGNITION SEQUENCE ALLOWING GAS VALVES

TO OPEN BEFORE THE HOT SURFACE IGNITER IS UP TO IGNITION

TEMPERATURE.

NOTE: ANY BYPASS OR ALTERATION OF THE UNITS SAFETIES WILL

RESULT IN VOIDING THE APPLIANCE WARRANTY.

Before performing any troubleshooting familiarize yourself with the particular

appliance.

Refer to the SEQUENCE OF OPERATION and the connection diagram located

on page 15 before continuing.

Make sure the appliance is connected to a 120V AC power supply, manual

gas valve is in the ON position, and all electrical connections are secure

before continuing to troubleshoot this appliance.

CAUTION

THE WATER HEATER IS POLARITY SENSITIVE. BEFORE APPLYING

ELECTRICITY TO THIS HEATER BE CERTAIN THAT SUPPLY HEATED WIRE

TO GROUND CHECK INDICATES ZERO VOLTAGE.
