22

To inspect or replace an anode:

The anodes on this heater are easily accessible from the top of the

heater making replacement simple and quick.

1. Turn the heater off per the lighting instructions. Connect a hose to the

drain valve . Locate the hose's discharge in an area where hot water

will not cause any damage or injury.

2. Open the drain valve to flush any sediment out of the bottom of the

heater.

3. Shut off the cold water supply. Make sure all hot water fixtures and

circulating pumps are turned off.

4. Wait for water flow from the hose to stop. Remove the anode using a

socket of the appropriate size Sometimes a pry bar will be required to

loosen the anode plug . Do not use an impact wrench.

5. Inspect and replace the anode as required. Use a pipe tape or sealant

when reinstalling the anode.

6. Close the drain valve . Open a hot water fixture to allow air to escape.

Open the cold water supply to heater and allow the tank to fill. Follow

the lighting instructions.

7. Check your anode and drain valve for leaks.

DRAIN VALVE AND ACCESS PANELS

The heaters are equipped with a 3/4" drain valve.

An access panel covers the cleanout opening in the tank which is sealed

by a gasket and cover, figure 25.

RELIEF VALVE

At least twice a year, the temperature and pressure relief valve should be

checked to ensure that it is in operating condition. To check the relief valve,

lift the lever at the end of the valve several times. The valve should seat

properly and operate freely.

If water does not flow, remove and inspect for obstructions or corrosion.

Replace with a new valve of the recommended size as necessary.

Inspection of the valve should be performed at least every three years. Do

not attempt to repair the valve, as this could result in improper operation

and a tank explosion. In areas with poor water conditions, it may be

necessary to inspect the T&P valve more often than every three years.

CAUTION

BEFORE MANUALLY OPERATING THE VALVE, MAKE SURE THAT A DRAIN

LINE HAS BEEN ATTACHED TO THE VALVE TO DIRECT THE DISCHARGE

TO AN OPEN DRAIN. FAILURE TO TAKE THIS PRECAUTION COULD MEAN

CONTACT WITH EXTREMELY HOT WATER PASSING OUT THE VALVE

DURING THIS CHECKING OPERATION.

If the temperature and pressure relief valve on the heater discharges

periodically or continuously, it may be due to thermal expansion of water in

a closed water supply system, or, it may be due to a faulty relief valve.

Thermal expansion is the normal response of water when it is heated. In

a closed system, thermal expansion will cause the system pressure to

build until the relief valve actuation pressure is equaled. Then, the relief

valve will open, allowing some water to escape, slightly lowering the

pressure.

Contact your water supplier or local plumbing inspector on how to control

this situation.

Two common corrections are listed in the Checklist and Service Information

which appears later in this manual.

ABOVE ALL, DO NOT PLUG THE TEMPERATURE AND PRESSURE RELIEF

VALVE. THIS IS NOT A SOLUTION AND CAN CREATE A HAZARDOUS

SITUATION.

CIRCULATING PUMP

The water heating system may include a circulating pump. Where used, it

should be lubricated as directed by the circulator manufacturer.

VENT SYSTEM

Examine the vent system every 3 months. Points of inspection are as

follows:

1. Check for obstructions and/or deterioration of vent piping and vent

hood. Replace immediately where needed.

2. Vent pipe and vent hood screen should be cleaned of foreign material

and soot. The screen is located inside the vent hood outlet and is

accessible from the outside of the hood. Do not reach inside the vent

hood when the heater is in operation.

3. Check all vent system connections for leakage and reseal as required

using Hi Temp Silicone sealer or equivalent.
