Model AV2-N4X

AV2-N4X Instruction Manual

Rev. 1.1

Page 3 of 6

3.0 Specifications

3.1 Strobe

Specifications:
Voltage:

12VDC,

24VDC,

50/60HZ

120VAC

50/60HZ,

240VAC

50/60HZ

(See specifications label for voltage rating)

Mount:

1/2"

Pipe

Operating Current:

0.44 Amps at 12VDC,

0.22

Amps

at

24VDC,

0.10

Amps

at

120VAC,

0.07

Amps

at

240VAC

Dome Colors:

Amber, Blue, Clear, Green, Red, Magenta

Operating Temperature:

-31°F to 150°F

Light Source/Lamp Style:

Strobe Tube

Lamp

Life:

7,000

Hours

Candle Power Peak:

175,000

Flash Rate/Minute:

60-80

Joules per Flash:

1.75

Intensity Candela:

40 Amber, 20 Blue,50 Clear, 20 Green, 10 Red

Enclosure Rating:

Type 4

Approvals:

UL Listed, CSA Certified, CE Pending

Dimensions:

5"H

x

3"Diameter

Warranty:

1

Year
