1.7 FLOW DIAGRAM
Detcon Model 971-071170-LRY Gas Detection System PG.7
CAL
Flow
Meter
Set
500-1000
ml/m
VENT
SENSOR
Sample In
P1
P2
PUMP
Flow
Switch
Moisture Filter
Stainless Steel
Note:
All NEMA
4X exterior
tubing is
Teflon except the
one from Sensor #1 to the
control enclosure. It should be
stainless steel.
All NEMA
7X
exterior tubing is stainless
steel.
All interior tubing is
polyvynle.
Liquid
Level
Module
