1.2.2 Field Replaceable Sensor
Detconꞌs infrared gas sensors are field proven, plug-in sensors with over-sized gold-plated connections that
eliminate corrosion problems. The sensor can be accessed and replaced in the field easily by releasing the
locking screw and unthreading the splashguard adapter assembly.
NOTE
Detconꞌs combustible sensors have a long shelf life and are supported by an industry-
leading warranty.
Figure 6 Plug-in Sensor
