Model CXT-IR
and the other for the CXT transceiver. For a more detailed description of the Register Map please contact
Detcon.
Table 3 CXT-IR Register Map
Offset Name R/W Comment
0000 CXT-IR-100 Device Type R = 36
0001 Range R/W Detectable Range
0002 Reading R Current Gas Reading
0003 Calibration Level R/W Auto Span Level
0004 Life R Sensor Life
0005 Sensor Faults R Fault bits
0006 Sensor Model R DM (set to 1)
0007 Days since Calibration R
0008 Reserved R
0009 Reserved R
0010 Sensor Temperature R
0011 DECIMAL R/W
0012 Temperature Compensation R/W
0013 Reserved R
0014 COUNTS R/W
0015 CONTROL R/W
0016 String R Set during production/test
0017 String R Set during production/test
0018 String R Set during production/test
0019 String R Set during production/test
0020 String R Set during production/test
0021 String R Set during production/test
0022 Reserved R/W NOT USED
0023 Sensor Controller Version R Year.Week
0024 Reserved R
0025 Reserved R
0026 Reserved R
0027 Wireless Controller Version R Major.Minor
0028 Reserved R
0029 Radio Firmware Version R 00.Major
0030 Radio Firmware Version R Minor.Build
0031 Radio Software Version R Major.Minor
0032 Wireless ID High R 00.XX
0033 Wireless ID Low R XX.XX
0034 RF Channel R Wireless RF Channel (Set in Display)
0035 Network ID R Defaults to RF Channel (Set in Display)
0036 Modbus Address R CXT Modbus Address (Set in Display)
RXT-320 Compatible Registers for Wireless Transceiver
8192 RXT-320 Device Type R 22 (for compatibility)
8193 Reserved --
8194 Reserved --
8195 Reserved --
8196 Reserved --
8197 Reserved --
8198 Reserved --
