STEP 8
A. Install Doors by fitting the pins in the top of the door into the holes in the Top Front Brace.
B. Place washers on the pins on the bottom of the doors, then fit the Bottom Front Brace onto the
pins and secure the brace using 1 3/4” bolts and nuts as in illustration 8A.
ILLUSTRATION 8A
ILLUSTRATION 8B
1” Pins 1” Pins
C. Tap two 1” pins into the back
panel, two into the holes on the
inside of the Bottom Front Brace
and two into each Side Panel as in
illustration 8B. These will hold the
Bottom Shelf.
