STEP 6
A. Lay Back Panel flat on a smooth surface with holes up.
B. Attach Side Panels with 1 3/4” bolts and hex nuts. After inserting bolts(s) thru the holes in the Side
Panels, thru the holes in the long edges of the Back Panel, place a hex nut on the tip of your finger,
align nut with bolt and tighten.
C. Look ahead to step 7 which shows side panels attached to back panel.
NOTE: Make sure you position the side panels according to Drawer Glides (left or right). The Back
Panel is 1 1/4” shorter than the Side Panels at the top.
STEP 7
A. Invert cabinet assembly
from step 6.
B. Take the Top Front Brace
(with magnet blocks), insert
the pins in the brace ends
into the slots on the inside
of the front legs of the Side
Panel and slide down until
the brace is aligned with the
set of holes in the Side Panel
as illustrated.
C. Secure brace with 1 3/4”
bolts and hex nuts as in
step 6
