Axxess Interface ASWC - Manual (Page 2)

Table of Contents
Preface
.............................................................................................. 3
Overview
– Introduction to the ASWC Interface and Wiring Harness .................4-5
ASWC
– Section 1: Installation ....................................................................6-7
– Section 2: Programming ................................................................8-9
– Section 3: Troublshooting
Auto Detect Mode ...................................................................... 10
Manual Programming ...........................................................10-13
Changing Radio Type ............................................................13-14
Manual Radio Type Programming .........................................14-15
– Section 4: Remapping
Remapping SWC Buttons ........................................................... 16
Resetting Original SWC Settings ................................................ 17
ASWC Ledgend
– Vehicle LED Feedback ..................................................................... 18
– Radio LED Feedback ..................................................................18-19
– Button Assignment (remapping/manual programing) ....................... 19
Caution: Metra recommends disconnecting the negative battery
terminal before beginning any installation. All accessories, switches,
and especially air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the aftermarket radio.
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 AxxESSINTERfACE.COM
