Axxess Interface ASWC User Manual
Axxess Interface For the car

METRA. THE WORLD’S BEST KITS.™
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932
metraonline.com
REV
. 7/13/2012
INST
ASWC
INSTALLATION INSTRUCTIONS FOR PART ASWC
IGNITION
TERMINALS
WIRE
CUTTER
M3.5
M2.6
M3
M5
M4
ISO
6
2.5
1.5
KIT FEATURES
• One Interface does it all - No additional interfaces needed
• Designed to be compatible with all major radio brands
• Auto detects vehicle type, radio connection, and presets controls
• Can be manually programmed for most vehicles
• Memory retains settings even after battery disconnection or
interface removal
• Connection placements are all organized behind the radio
• USB updatable
INTERFACE COMPONENTS
• ASWC Interface • 12-pin harness with male 3.5 mm connector
• Female 3.5 mm connector with Brown and Brown/White wires
• 12k-ohm resistor
TOOLS REQUIRED
• Cutting tool • Crimping tool • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
Axxess Steering Wheel Control
Interface Installation Manual
ASWC
