Avigilon ACC Camera Installation Tool Version 4.12 - Manual (Page 9)

Using the Installation Tool
5
The camera will attempt to obtain an address from a DHCP server. If it cannot, the
camera will default to addresses in the 169.254.x.x range.
o Use the following IP address: select this option to manually assign a static IP address
for the camera.
Enter the IP Address, Subnet Mask and Gateway you want the camera to use.
3. Select the Control Port for connecting to the camera. This port is also used for manually
discovering the camera on the network.
4. Select the Enable Multicast check box to enable multicast streaming from the camera. You must
enable multicast to set up redundant connections to multiple servers.
Use the default generated IP Address, TTL and Base Port, or enter your own values.
5. Click OK.
Image and Display
Use the Image and Display dialog box to adjust the camera’s display settings for live and recorded video.
Note: Some of the following options may not appear if the camera feature cannot be adjusted through
the application.
1. Click Image and Display. The Image and Display dialog box is displayed.
