Avigilon Control Center 5 System Integration Guide with Lenel Facility Commander Wnx
7
Avigilon FCWnx Gateway
The Avigilon FCWnx Gateway is composed of two parts: the Avigilon FCWnx Gateway
Windows service that runs automatically in the background, and the Avigilon FCWnx
Gateway configuration application that is used to configure the connection and alarm
mappings between the Facility Commander Wnx and the Avigilon systems.
Configuring Server Settings
Configure the Avigilon FCWnx Gateway to access the two applications.
The configuration application remembers the server configuration, so you do not need to
repeat this procedure if the settings remain the same.
After you install the integration software, the Configuration Tool automatically opens. To
access it manually, select All Programs > Avigilon > Avigilon FCWnx Gateway > Avigilon
FCWnx Gateway Admin Tool.
• If you upgraded your integration and all the configurations were successfully
imported, you will automatically see the Configuration Tool window. Click
Configure Connections.
• If this is a new installation, you will automatically see the Configure
Connections dialog box. Click Add.
a.
In the following dialog box, enter the Avigilon Server IP Address, User
Name and Password, then click OK.
Use the username and password you created for the integration. See Adding
an Integration User in Avigilon on page 5.
