6
1 INTRODUCTION
1.1 FEATURE
z H.264 Hardware Codec Video Compression
z Recording Image Per Second (IPS): 240 IPS for 8/16 channels
z Display Image Per Second (IPS): 480 IPS for 8/16 channels
z IPS and Recording Quality Adjustable (by channel)
z User Friendly Operation (Front Panel Button/ Remote Controller/ Mouse)
z Support CMS (Central Management System) and 3GPP.
z Audio Backup / Audio Streaming.
z Support Day/Time and Event search function via Ethernet remote control mode or Local
site
z Support PPPoE/ Static/ DHCP IP/ DDNS/ RS-232/ RS-485
1.2 SPECIFICATION
Model Number 8 Channel 16 Channel
MONITORING
Video Input 8 x BNC 16 x BNC
Video Looping 8 x BNC 16 x BNC
Video Output 1xMain Monitor, 1xSpot Monitor, 1xS-video, 1X VGA (Optional)
Display Resolution (Live) 720x480 (NTSC), 720x576 (PAL)
Display Rate 30 IPS per channel (NTSC), 25 IPS per channel (PAL)
Spilt Screen 1, 4, 9 1, 4, 9, 13, 16
RECORDING & PLAYBACK
Compression H.264
Recording Resolution 720x240 (NTSC), 720x288 (PAL) or 360 x 240 (NTSC), 360 x 288
(PAL)
Recording Rate 720x240 (NTSC 120 IPS), 720x288 (PAL 100 IPS) or 360 x 240
(NTSC 240 IPS), 360 x 288(PAL 200 IPS)
Recording Quality 4x Levels (Best, High, Medium, Low)
Recording Mode Manual, Scheduled (5 Recording Schedule)
