6
1 INTRODUCTION
1.1 FEATURE
¾ H.264 hardware-based codec
¾ Triplex Function (Simultaneously playback, record and remote viewer)
¾ Adjustable recording resolution (Half D1 or CIF) & rate
¾ 1 x Audio In & 1 x Audio Out
¾ Intelligent video content analytics VMD
¾ 3.5” SATA HDD Support
1.2 SPECIFICATION
4 CH H.264 DVR 8CH H.264 DVR
Video Input Composite: 4 x BNC Composite: 8 x BNC
Video Output 4 Video Output (1Vp-p/75ohm) for lopping, 2 x Composite (1 x CRT / 1 x
SPOT), 1 x VGA
Display Resolution (Live) 720 x 480 (NTSC) / 720*576 (PAL)
Display Rate 30 IPS per channel (NTSC), 25 IPS per channel (PAL)
Split Screen 1,4 1,4,9
RECORDING & PLAYBACK
Compression H.264 Hardware-Based Codec
Recording Resolution/ Rate
(Adjustable) NTSC: 720*240, 360*240
PAL: 720*288, 360*288
Recording Quality 4 x Levels ( Bes/High/ Medium/Low)
Recording Rate ( Half D1) NTSC:720*240 up to 60
PAL: 720*288 up to 50
NTSC: 720*240 up to 120
PAL: 720*288 up to 100
