23
Operation (continued)
Depth scale method (Fig. 31)
1. With the switch (1) OFF, turn the feed handle (2) until the
drill bit tip (3) slightly touches the top of the workpiece (4).
2. Hold the feed handles in that position.
3. Loosen the depth lock knob (5).
4. Spin the depth scale hub (6) until the desired drilling depth is
at the scale pointer.
5. Lock the depth lock knob. The chuck and drill bit will now
drill into the workpiece only to the distance selected on the
depth scale.
General Drilling Guidelines
WARNING: To avoid injury, make sure the chuck key is removed from the chuck before
starting any drilling operation.
Drilling speeds
Important factors when determining the best drilling speed:

Type of material

Size of the hole to be drilled

Type of drill bit or cutter

Desired quality of the cut
Remember, smaller drill bits require greater speed than large drill bits. Softer materials require
greater speed than harder materials.
