4
INSTALLATION
Upon receipt of machine, uncrate and check all parts.
Report to your carrier any damage to machine and fi le
Proof of Loss Claim with same.
• Place motor in position on motor pivot post and
install V-Belt.
• Be sure motor specifi cations correspond with your
power line.
• Place machine so that each leg is carrying its
share of the load.
Read instructions carefully.
OPERATION
• Do not apply too much feed at fi rst on new
blade.
• Start cut carefully and the blade will last much
longer.
• Make sure all four legs are in solid contact
with the fl oor.
• Keep blade guides as close to both Vise Jaws
as possible.
PLACING BLADE ON SAW
• Raise frame to extreme height.
• Remove blade guard on high side of frame.
• Turn idler band wheel tension screw until the
blade will slide on wheels easily. With blade un-
coiled, place in roller guides and between brush-
es, then over band wheels.
• Grasp blade on frame side and push toward guide
bracket beam to hold in position, then turn tension
screw until the blade is taut.
• Start motor and tighten blade to proper operating
tension.
• Make certain that the blade teeth point same way
blade is running; if not, this can he accomplished
turning the blade inside out.
AUTOMATIC STOP
When the saw blade has completed the cut through
the material, the saw frame drops on a trigger to
which a rod is attached. This rod passes through
the frame of the machine to the switch on the oppo-
site side, and opens the contacts, thereby stopping
the saw.
It will be necessary to raise saw frame clear of the
trigger before machine can he started.
FIXED VISE JAW
The two pins in the fi xed vise jaw should be kept in
place in order to insure square cuts. When cutting
angles, these pins must be removed and the vise
jaws turned to desired position and tightened with
clamp bolts. These pins enable operators to quickly
relocate fi xed vise jaw for 90° cutting. For fi nal
adjustment, the vise jaw should be squared with
the blade.
The sliding vise jaw should be loosened and pushed
against fi xed vise jaw and then tightened.
NEW BLADE TENSIONING DEVICE
On saws equipped with blade tensioning device,
tighten hand wheel tension screw until gauge bar is
fl ush with end of casting.
INSTALLATION, OPERATION and MAINTENANCE
of the No. 5 WELLS METAL CUTTING BANDSAW
The No. 5 METAL CUTTING BANDSAW was designed for effi cient performance, and with proper care will
give you many years of dependable service.
Each saw is completely assembled, checked thoroughly and subjected to a test run; no further adjustments
should be necessary.
This manual has been prepared to assist you in the proper installation, operation and maintenance of your
new Wells Metal Cutting Band Saw. If you should desire additional information or assistance, we suggest you
contact your dealer’s service representative.
Read this manual carefully. It was prepared to help you.
