The eight (8) keys, arranged in two four-key groups, are called screen function keys. A screen function
key is only active when a corresponding function or menu option is present next to that key. The Function
keys are designated F1 through F8, as shown in Figure 2-2.

Figure 2-2. Function key layout.

The entry of numeric characters via the main keypad is straightforward: simply press the desired key.
However, in certain Management Function screens it may be necessary to enter alphabetic characters, a
procedure that’s available with the On-Screen keypad, explained on next page.

Figure 2-3.

Alphanumeric

keypad.

F

UNCTION

K

EYS

M

AIN

K

EYPAD

CTRL

F1
F2
F3
F4

F5
F6
F7
F8
