Appendix

Main Technical

Specifications

GNSS reception:

220 GNSS channels:

• GPS L1C/1, L2P and L2C

• GLONASS L1 C/A and L2 C/A

• SBAS: Code and carrier (WAAS/EGNOS/MSAS/GAGAN)

Phase Center Diagram (NGS antenna name: SPP89823-10)

Performance:

• Real-time kinematic accuracy for baselines < 30 km

(17 miles):

–

Horizontal: 10 mm (0.033 ft) + 1 ppm

–

Vertical: 20 mm (0.065 ft) + 1 ppm

• Real-time performance:

–

Initialization time: < 10 seconds typical for baselines
< 20 km (12.5 miles)

–

Initialization reliability: >99.9%

Communication:

• Wireless (Bluetooth 2.0 class 2), SPP profile

• RS232 serial port (115200 baud, no flow control, no

parity check, 8 data bits)

Physical:

• Overall dimensions:

–

Diameter: 205 mm (8.1”)

–

Height: 62 mm (2.4“)

• Weight: 0.65 kg (1.4 lb) approximately

L1 78.2 mm
L2 62.2 mm
