Operating the Spreader (continued)
Model # SP-7550
DISCHARGE BAFFLE and INVERTED-V INSTRUCTIONS
• The 7550 uses an Inverted-v design over the auger area. This
inverted-v (D5510) is used to reduce load to the auger drive train. It
must not be removed unless servicing the unit.
• WARNING: Always disconnect power source before attempting to
remove material baffle.
• The 7550 uses a discharge baffle (D5517) to reduce material
leakage. It must not be removed unless servicing the unit.
• BAFFLE EXTENSION INSTRUCTIONS
• The Baffle Extension (D-5503) is intended to be used with very dry
products that free-flow with little effort. The baffle is designed to
keep these types of materials from leaking out.
• If you plan on using damp/wet materials, you should remove this
baffle by removing the self-drilling screws.
• If you are using a sand/salt mixture, remove baffle extension.
D5510
D5517
D5503
