© Trynex International 2011 (REV 001)
16
Harness Diagram
Model # SP-7550
D6785 Spreader Auxiliary Harness
D6786 Vehicle Auxiliary Harness
28"
LOAD VIEW
BLACK TO PACKARD
BLACK TO
MOLDED 2-WAY
BLACK-BLUNT
BURY LEADS
IN CONDUIT
28"
RED TO PACKARD
RED TO
MOLDED 2-WAY
RED-BLUNT
12"
BLUNT (2)
A-RED
B-BLACK
2-WAY CHMSL
3"
A B
MOLD CAP
12" RD
4' RD
27' RD
310"
14"
27'
BURY 12" WIRE IN CONDUIT
RD
BK
12" BK
34"
12"
14"
4' BK
27' BK
TAPE
