Harness diagram, Model # sp-7550 – SnowEx SP-7550 User Manual
Page 14
© Trynex International 2011 (REV 001)
14
Harness Diagram
Model # SP-7550
Red
Black
End View
Red
10 GA
Auger+
White
10 GA
Spinner+
Green
10 GA
Auger -
Orange
10 GA
Vibrator -
Hot
Circuit
Spinner+
10 GA White
Auger+
10 GA Red
Vibrator+
12 GA Orange
Spinner-
10 GA Black
Auger-
10 GA Green
Vibrator-
12 GA Blue
Grd
Circuit
Black
10 GA
Spinner -
Blue
12 GA
Vibrator -
Mold Cap
Black
3/8” Terminal w/Heat Shrink
124” Tubing
Front View
Black to
Negative -
Red to
Positive +
Red
D6322 Vehicle Harness
D6341 Control Power Cable
