15 © Trynex International 2011 (REV 001)
Harness Diagram
Model # SP-7550
D5524 Spreader Harness
D5525 Controller
Black
Negative (-)
Red
Positive (+)
Vibrator
Red Positive (+)
Spinner
Red Positive (+)
Auger
Red Positive (+)
Vibrator
Black Negative (-)
Spinner
Black Negative (-)
Auger
Black Negative (-)
47"
5"
SPINNER + RED
AUGER + RED
VIBRATOR + RED
87 1/4"
58"
LOAD
VIEW
BLACK RED
BLACK
SPINNER PLUG
A
B
RED
VIBRATOR
PLUG
AUGER
BLACK - SPINNER
LOAD VIEW
BLACK - AUGER
BLACK - VIBRATOR
IMPORTANT: In the off season remove control
and put in a cool dry place. The interior summer
temperatures could damage circuit board and
void warranty.
