ShelterLogic 62783 Garage-in-a-Box RoundTop - Manual (Page 6)

05_62780_62783_0B Page 6
802130
10115
802695
802695
13201 800923
01010
01011
01010
01011
03032
800939
03032
01010
01010
800920
802129
800921
03032
800939
03032
01010
01010
800920
802130
800921
10115
802695
13202
800958
01011
01010
5. connecT ReMAInInG MIDDle RIBs
6. connecT ReAR enD RIB
ShelterLock ® connections use #03032 (1 7
/
8
") Bolts. Cover Rail Clamp connections use #10115 (1 5
/
8
") Bolts.
Cross Rails face to the inside of the garage.
ShelterLock ® connections use #03032 (1 7
/
8
") Bolts. Cover Rail Clamp connections use #10115 (1 5
/
8
") Bolts.
Middle Rib Cover Rail Clamps ShelterLock ® Middle Rib Connection
End Rib Cover Rail Clamps
ShelterLock ® End Rib Connection
