11.2 Technical data, weighing
Technical data, weighing seca 761
Calibration in accordance with Directive 2009/
23/EC
Class IIII
Maximum load 150 kg
Minimum load 10 kg
Graduations 1 kg
Zero adjustment range 20 kg
Accuracy on initial calibration:
• 10 kg to 50 kg
• 50 kg to 150 kg ±0.5 kg
±1 kg
Technical data, weighing seca 750/760/762
Maximum load 150 kg / 320 lbs / 23 sts
Minimum load 10 kg / 20 lbs / 1 sts
Graduations seca 750/760 1 kg / 1 lbs / 1 lbs
Graduations seca 762 0,5 kg / 1 lbs / 1 lbs
Zero adjustment range 20 kg / 45 lbs / 3 sts
Accuracy:
• 10 kg to 80 kg
• 80 kg to 150 kg
• 20 lbs to 180 lbs
• 180 lbs to 320 lbs
• 1 sts to 12 sts
• 12 sts to 23 sts ±1 kg
±1.25 %
±2.2 lbs
±1.25 %
±0.2 sts
±1.25 %
