Page 4
520-199-000
1/01
Model S1F Non-Metallic Design Level 2 Page 2
Pump Brand
S= SandPIPER II
®
Pump Size
1F=1" Full Flow
Check Valve Type
B= Ball
Design Level
2= Design Level 2
Wetted Material
K= PVDF
N= Nylon
P= Polypropylene
Diaphragm Check Valve Materials
1= Santoprene/Santoprene
2= PTFE-Santoprene Backup/PTFE
3= PTFE Pumping, PTFE-Santoprene
Backup Driver/PTFE
Check Valve Seat
K= PVDF
N= Nylon
P= Polypropylene
Non-Wetted Material Options
A= Painted Aluminum
J= Painted Aluminum PTFE
Q= Epoxy Coated Aluminum
K= PTFE Coated Aluminum
L= PTFE Coated Aluminum with PTFE
Coated Hardware
R= Epoxy Coated Aluminum with
PTFE Coated Hardware
Porting Options
A= ANSI Flange
D=DIN Flange
7= Dual Porting (ANSI)
8= Top Dual Porting (ANSI)
9= Bottom Dual Porting (ANSI)
Pump Style
D=RuppGUARD™ with
Electronic Leak Detection
(110V)
E= RuppGUARD™ with
Electronic Leak Detection
(220V)
M=RuppGUARD™ with Mechanical
Leak Detection
S= Standard
V= RuppGUARD™ with Visual
Leak Detection
Pump Options
0= None
1= 3M Muffler
2= Mesh Muffler
3= High temperature Air
Valve w/Encapsulated
Muffler
4= High temperature Air
Valve w/3M Muffler
5= High temperature
AirValvew/Mesh Muffler
S1F Non-Metallic · Design Level 2· Ball Valve
Check
Diaphragm/
Check
Non-Wetted
Shipping
MODEL
Pump Pump
Valve
Design
Wetted
Check Valve
Valve
Material
Porting
Pump
Pump
Kit
Weight
Brand
Size
Type
Level
Material
Materials
Seat
Options
Options
Style
Options Options
lbs. (kg)
S1FB2P1PAAS000.
S
1F
B
2
P
1
P
A
A
S
0
00.
53 (24)
S1FB2P2PAAS000.
S
1F
B
2
P
2
P
A
A
S
0
00.
53 (24)
S1FB2K1KAAS000.
S
1F
B
2
K
1
K
A
A
S
0
00.
65 (29)
S1FB2K2KAAS000.
S
1F
B
2
K
2
K
A
A
S
0
00.
65 (29)
S1FB2P3PAAV000.
S
1F
B
2
P
3
P
A
A
V
0
00.
58 (26)
S1FB2K3KAAV000.
S
1F
B
2
K
3
K
A
A
V
0
00.
77 (35)
Explanation of Pump Nomenclature
Kit Options
00.=None
P0.=0-30VDC Pulse Output Kit
P1.=Intrinsically-Safe 10-30VDC Pulse Output Kit
P2.=110/120 or 220/240VAC Pulse Output Kit
P3.=Intrinsically-Safe 110/120VAC Pulse Output Kit
P4.=Intrinsically-Safe 220/240VAC Pulse Output Kit
SP.=Stroke Indicator Pins
