520-199-000 1/01 Model S1F Non-Metallic Design Level 2 Page 1
Quality System
ISO9001 Certified
Environmental
Management System
ISO14001 Certified
S1F
Non-Metallic
Design Level 2
Ball Valve
Air-Powered Air-Powered Air-Powered Air-Powered Air-Powered
Double-Diaphragm Pump
Double-Diaphragm Pump Double-Diaphragm Pump Double-Diaphragm Pump Double-Diaphragm Pump
ENGINEERING, PERFORMANCE
& CONSTRUCTION DATA
CE
U.S. Patent #
5,996,627; 400,210
Other U.S. Patents
Applied for
Santoprene Santoprene Santoprene Santoprene Santoprene ® Injection molded thermoplastic elastomer with no fabric layer. Long mechanical flex 212°F -10°F 50° to 212°F
life. Excellent abrasion resistance. 100°C -23°C 10°C to 100°C
PTFE PTFE PTFE PTFE PTFE Chemically inert, virtually impervious. Very few chemicals are known to react chemically with
Teflon: molten alkali metals, turbulent liquid or gaseous fluorine and a few fluoro-chemicals such as
212°F -35°F 50°F to 212°F
chlorine trifluoride or oxygen difluoride which readily liberate free fluorine at elevated temperatures. 100°C -37°C 10°C to 100°C
PVDF PVDF PVDF PVDF PVDF 200°F -10°F
-93°C -13°C
P o l y p r o p y l e n e P o l y p r o p y l e n e P o l y p r o p y l e n e P o l y p r o p y l e n e P o l y p r o p y l e n e 150°F -40°F
65°C 5°C
N y l o n N y l o n N y l o n N y l o n N y l o n 150°F -40°F
65°C 5°C
Materials Materials Materials Materials Materials Maximum* Maximum* Maximum* Maximum* Maximum* Minimum* Minimum* Minimum* Minimum* Minimum* Optimum** Optimum** Optimum** Optimum** Optimum**
*Definite reduction in service life.
**Minimal reduction in service life at ends of range.
Operating T Operating T Operating T Operating T Operating Temperatures emperatures emperatures emperatures emperatures
For specific applications, always consult “Chemical Resistance Chart” Technical Bulletin
SandPIPER II ® pumps are designed to be powered only by compressed air.
INTAKE/DISCHARGE PIPE SIZE
1" ANSI Flange
o r
PN10 25mm DIN Flange
CAPACITY
0 to 45 gallons per minute
(0 to 170 liters per minute)
AIR VALVE
No-lube, no-stall
design
SOLIDS-HANDLING
Up to .25 in. (6mm)
HEADS UP TO
100 psi or 231 ft. of water
(7 bar or 70 meters)
DISPLACEMENT/STROKE
.17 gallon / .64 liter
CAUTION! Operating temperature limitations are as follows:
Air Inlet Side View
Air Exhaust Side View
