SANDPIPER RS30 Metallic User Manual
Page 6
rs30mdl1sm-rev0614
Model RS30 Metallic Page 4
Dimensions: RS30 Metallic Standard NPT Port Connections
K
P
AIR INLET
1" NPT
L
M
P
N
A
D
F
E
J
G
F
H
B
C
SUCTION
PORT
3" NPT
DISCHARGE PORT
3" NPT
1" NPT HIGH FLOW
EXHAUST MUFFLER
BOTH SUCTION AND DISCHARGE PORTS ARE
AVAILABLE WITH 3" BSP CONNECTIONS
English
.125
Metric
3mm
Aluminum
Cast Iron
Stainless
Alloy "C"
Aluminum
Cast Iron
Stainless
Alloy "C"
A
2.35
2.41
60
62
B
15.82
15.88
402
403
C
17.15
17.21
436
438
D
29.98
30.04
761
763
E
32.08
32.14
815
817
F
3.74
95
G
11.40
290
H
13.50
343
J
25.16
639
K
19.65
499
L
10.13
257
M
12.00
305
N
11.75
299
P
.52
13
Q
.62
16
