SANDPIPER RS30 Metallic User Manual
Page 4
rs30mdl1sm-rev0614
Model RS30 Metallic Page 2
Check
Diaphragm/
Check
Non-Wetted
Shipping
Model
Pump
Pump
Valve
Design
Wetted
Check Valve
Valve
Material
Porting
Pump
Pump
Kit
Weight
Brand
Size
Type
Level
Material
Materials
Seat
Options
Options
Style
Options
Options
lbs. (kg)
RS30B1ABBANAS00
RS
30
B
1
A
B
B
A
N
A
S
00
141 (64)
RS30B1AEEANAS00
RS
30
B
1
A
E
E
A
N
A
S
00
141 (64)
RS30B1AGTANAS00
RS
30
B
1
A
G
T
A
N
A
S
00
141 (64)
RS30B1ANNANAS00
RS
30
B
1
A
N
N
A
N
A
S
00
141 (64)
RS30B1A1EANAS00
RS
30
B
1
A
1
E
A
N
A
S
00
141 (64)
RS30B1IBBANAS00
RS
30
B
1
I
B
B
A
N
A
S
00
240 (109)
RS30B1IEEANAS00
RS
30
B
1
I
E
E
A
N
A
S
00
240 (109)
RS30B1IGTANAS00
RS
30
B
1
I
G
T
A
N
A
S
00
240 (109)
RS30B1INNANAS00
RS
30
B
1
I
N
N
A
N
A
S
00
240 (109)
RS30B1I1EANAS00
RS
30
B
1
I
1
E
A
N
A
S
00
240 (109)
RS30B1SBBANAS00
RS
30
B
1
S
B
B
A
N
A
S
00
219 (99)
RS30B1SGTANAS00
RS
30
B
1
S
G
T
A
N
A
S
00
219 (99)
RS30B1SNNANAS00
RS
30
B
1
S
N
N
A
N
A
S
00
219 (99)
RS30B1S1EANAS00
RS
30
B
1
S
1
E
A
N
A
S
00
219 (99)
RS30B1HGTANAS00
RS
30
B
1
H
G
T
A
N
A
S
00
260 (118)
Explanation of Pump Nomenclature, RS30 Metallic · Design Level 1· Ball Valve
Pump Brand
RS= SANDPIPER
®
AirVantage
Pump Size
30 = 3"
Check Valve Type
B = Ball
Design Level
1 = Design Level
Wetted Material
A = Aluminum
I = Cast Iron
S = Stainless Steel
H = Alloy C
Diaphragm Check Valve Materials
1 = Santoprene/Santoprene
2 = PTFE-Santoprene/PTFE
B = Nitrile/Nitrile
C = FKM/PTFE
E = EPDM/EPDM
I = EPDM/Santoprene
G = PTFE-Neoprene/PTFE
N = Neoprene/Neoprene
Check Valve Seat
A = Aluminum
B = Nitrile
C = Carbon Steel
E = EPDM
N = Neoprene
S = Stainless Steel
T = PTFE
V = FKM
Non-Wetted Material Options
A = Painted Aluminum
J = Painted Aluminum w/PTFE
Coated Hardware
Y = Painted Aluminum with
Stainless Steel Hardware
Porting Options
N = NPT Threads
B = BSP (Tapered) Threads
A = ANSI Flange
D = DIN Flange
R = Raised Face 150#
Threaded ANSI Flange
Pump Style
A = Anodized Aluminum
Air Saving Valve
Note: Models listed in the table are for reference only. See nomenclature below for other models.
Pump Options
P = 110 VAC plug-in Electrical
Hook-up with High Flow
Metal Muffler
S = Self-Contained Electrical
Generation with High Flow
Metal Muffler
Kit Options
00.= None
P0.= 10-30VDC
Pulse Output Kit
P2.= 110/120 or 220/240VAC
Pulse Output Kit
SP.= Stroke Indicator Pins
