Solenoid Kit Selection
Before installing the Solenoid Kit, make certain it
is compatible with your specific pump model and
voltage.
894-001-000 · 894-002-000
894-003-000 · 894-004-000
Fit pump models:
PB¼-A
PB½-A PB½-T
PB¾-A EB½-A EB½-T
MP01P MP02P MP02T
MP02M MP03P S05
M05 S07 M07
S10 M10
894-005-000 · 894-006-000
894-007-000 · 894-008-000
Fit pump models:
PB1-A
PB1½-A PB2-A
EB1-SM EB1-M EB1½-SM
SE½-A SB1-A SA1-A
ET1-M ET1½-SM ST1-A
SB25-A SA25A ST25-A
MP04P MP07P MP03M
MP04M MP05M MP04D
MP05D S1F M1F
894-009-000 · 894-010-000
894-011-000 · 894-012-000
Fit pump models:
EB2-SM
EB2-M SB1½-A
SB2-A SA2-A SA2-M
SA3-A SA3-M SA4-A
SA4-M W09 W15
ET1½-M ET2-M ST1½-A
EB3-SM EB3-M EB4-M
SB3-A SB4-A ET3-SM
ET3-M SB40-A SA40-A
MP07D MP08M MP08B
MP08D MP10M MP12M
MP12D MP14M MP14D
S15 M15 S20
M20 S30 M30
Kit 894-001-000
110/120 VAC Solenoid · Kit includes:
Part No.
Description Qty
893-085-000 Valve (includes knurled nut) 1
219-002-000 Coil 1
241-001-000 Connector 1
541-001-000 Nut, Knurled 1
Kit 894-002-000
220/240 VAC Solenoid · Kit includes:
Part No.
Description Qty
893-085-000 Valve (includes knurled nut) 1
219-003-000 Coil 1
241-001-000 Connector 1
541-001-000 Nut, Knurled 1
Kit 894-003-000
12VDC Solenoid · Kit includes:
Part No.
Description Qty
893-085-000 Valve (includes knurled nut) 1
219-004-000 Coil 1
241-001-000 Connector 1
541-001-000 Nut, Knurled 1
Kit 894-004-000
24VDC Solenoid · Kit includes:
Part No.
Description Qty
893-085-000 Valve (includes knurled nut) 1
219-001-000 Coil 1
241-001-000 Connector 1
541-001-000 Nut, Knurled 1
Kit 894-005-000
110/120 VAC Solenoid · Kit includes:
Part No.
Description Qty
893-086-000 Valve (includes knurled nut) 1
219-002-000 Coil 1
241-001-000 Connector 1
541-001-000 Nut, Knurled 1
Kit 894-006-000
220/240 VAC Solenoid · Kit includes:
Part No.
Description Qty
893-086-000 Valve (includes knurled nut) 1
219-003-000 Coil 1
241-001-000 Connector 1
541-001-000 Nut, Knurled 1
Kit 894-007-000
12VDC Solenoid · Kit includes:
Part No.
Description Qty
893-086-000 Valve (includes knurled nut) 1
219-004-000 Coil 1
241-001-000 Connector 1
541-001-000 Nut, Knurled 1
Solenoid Kit Repair Parts
All parts available in kit form, or individually.
