SERVICE AND OPERATING MANUAL
¼” Natural Gas Regulator
Regulator for G05 Natural Gas Operated Pump
WARREN RUPP, INC. · A Unit of IDEX Corporation · P.O. Box 1568, Mansfield, Ohio 44901-1568 · (419) 524-8388 · Fax (419) 522-7867
4/06
©Copyright 2006 Warren Rupp, Inc. All rights reserved.
Superior regulation and excellent stability make the 020.057.000. Regulator ideal for lower flow
applications. Square head adjustment screw allows for easy in-field calibration. The 020.057.000.
is available with hand wheel adjustment, output pressure gauge and/or mounting bracket as
options.
Sensitivity
Max. Inlet
Pressure
Port Size
Outlet Ranges
Adjustment
Materials of
Construction
Diaphragm
Material
020.057.000.
1” WC
250 psig
17 BAR
1/4” NPT
adjustment screw
0-10, 0-30, 0-60, 0-120 psig
0-7, 0-2, 0-4, 0-8 BAR
Aluminum, Brass
Plated Steel, Buna-N
Nitrile Elastomer with
Dacron Fabric
0
2
4
6
8
1
0
1
1
0
2
0
4
0
6
0
8 0
1
0 0
1
2
0
1
4
0
1
6
0
1/4" NPT
IN
3.24
5.20
Gauge Port
1/4" NPT
.45
1.44
2.88
2.50
2.14
1/8" NPT
Vent Port
4.30
2.46
.89
1.22
1/4" NPT
Out
