SANDPIPER AIR DRYER User Manual
Air dryer, Intended use, Installation

A Unit of IDEX Corporation
WARREN RUPP, INC. A Unit of IDEX Corporation · P.O. Box 1568 · Mansfield, OH 44901-1568 · (419) 524-8388 Fax (419) 522-7867
Intended Use
This air dryer is designed to remove 99% of the water, rust
and other contaminants commonly present in compressed
air lines. Clean, dry air enhances the life and performance of
pneumatically-driven equipment.
Installation
This unit should be installed in the air line, between the air
compressor and any in-line filter, regulator, or air dryer. This
unit should be used in low humidity, and installed as far as
possible from the compressor. Do not operate this air dryer
below the minimum operating pressure range stated in the
specifications.
This unit is equipped with auto drain capability.
Air Dryer svc man.p65 7/99
AIR DRYER
020.046.007 · 020.047.007 · 020.048.008
Installation & Maintenance Guide
Specifications
AIR DRYER 020.046.007
Port size
¼" (.64cm)
Applicable air compressor
Approx. 2.2 kW
Operating pressure range
.15~1 MPa (1.5~10.2kg/cm2)
Proof pressure
1.5 MPa (15.3kg/cm2)
Flow rate
10.6 SCFM (300 l/min)
Ambient temp
36~140°F (2~60°C)
Fluid temp
36~140°F (2~60°C)
Auto drain
Normally-open type
Weight
.84 lbs. (.38kg)
AIR DRYER 020.047.007
Port size
½" (1.27cm)
Applicable air compressor
Approx. 11 kW
Operating pressure range
.15~1 MPa (1.5~10.2kg/cm2)
Proof pressure
1.5 MPa (15.3kg/cm2)
Flow rate
53 SCFM (1500 l/min)
Ambient temp
36~140°F (2~60°C)
Fluid temp
36~140°F (2~60°C)
Auto drain
Normally-open type
Weight
1.98 lbs. (.9kg)
AIR DRYER 020.048.008
Port size
1" (32.54cm)
Applicable air compressor
Approx. 22 kW
Operating pressure range
.15~1 MPa (1.5~10.2kg/cm2)
Proof pressure
1.5 MPa (15.3kg/cm2)
Flow rate
123.6 SCFM (3500 l/min)
Ambient temp
36~140°F (2~60°C)
Fluid temp
36~140°F (2~60°C)
Auto drain
Normally-open type
Weight
4.63 lbs. (2.1kg)
