com Model G05 Metallic •
10
Service & Repair Kits
Composite Repair Parts List
ATEX Compliant
LEGEND:
= Items contained within Gas End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
Item Part Number Description Qty.
1 031-174-000 Gas Valve Assembly 1
031-174-363 Gas Valve Assembly 1
2 050-022-600 Ball, Check 4
050-027-360 Ball, Check 4
3 095-116-000 Pilot Valve Assembly 1
095-116-363 Pilot Valve Assembly 1
4 114-023-157 Intermediate Bracket 1
5 115-152-151 Bracket, Mounting (Aluminum) 2
6 132-034-360 Bumper, Diaphragm 2
132-034-363 Bumper, Diaphragm 2
7 135-036-506 Bushing, Plunger 2
8 165-110-157 Cap, Gas Inlet 1
9 171-017-330 Capscrew, Flat Socket Head 4
1/4-20 X .50 (Aluminum)
10 170-044-330 Capscrew, Hex 5/16-18 X 1.00 8
11 170-045-330 Capscrew, Hex 5/16-18 X 1.25 (Alum) 40
170-045-330 Capscrew, Hex 5/16-18 X 1.25 (SS) 24
12 171-076-330 Capscrew, Flanged 1/4-20 X .75 4
13 171-077-330 Capscrew, Flanged 1/4-20 X 1.50 4
14 196-171-110 Chamber, Outer 2
196-171-157 Chamber, Outer 2
15 286-095-360 Diaphragm 2
16 286-096-600 Diaphragm, Overlay 2
17 312-110-157 Elbow, Suction (Aluminum Only) 2
18 312-111-157 Elbow, Discharge (Aluminum Only) 2
19 360-100-379 Gasket, Gas Inlet 1
20 360-108-360 Gasket, Pilot Valve 1
21 360-102-360 Gasket, Gas Valve 1
22 518-157-157 Manifold (see item 29) (Aluminum Only) 2
518-157-157E Manifold BSP (Tapered) (Alum Only) 2
23 518-158-110 Manifold, Suction (SS) 1
518-158-110E Manifold, Suction BSP (Tapered) (SS) 1
518-158-110W Manifold, Suction - 1/2" Welded Raised
Face #150 ANSI Flanged (SS) 1
24 518-159-110 Manifold, Discharge (SS) 1
518-159-110E Manifold, Discharge BSP (Tapered) (SS) 1
518-159-110W Manifold, Discharge - 1/2" Welded Raised
Face #150 ANSI Flanged (SS) 1
Item Part Number Description Qty.
25 545-004-330 Nut, Hex Flanged 5/16-18 (Alum) 24
545-004-330 Nut, Hex Flanged 5/16-18 (SS) 8
26 560-001-360 O-Ring 2
560-001-363 O-Ring 2
27 560-083-360 O-Ring (Aluminum Manifold) 4
560-083-360 O-Ring (Metallic Seats Only) 8
560-083-611 O-Ring (Metallic Seats Only) 8
720-064-600 Seal (Aluminum Manifold) 4
28 612-091-110 Plate, Outer Diaphragm 2
612-091-157 Plate, Outer Diaphragm 2
29 612-177-330 Plate, Inner Diaphragm 2
30 620-019-115 Pin, Actuator 2
31 675-042-115 Ring, Retaining 1
32 685-056-120 Rod, Diaphragm 2
33 720-012-360 Seal, U-Cup Shaft 4
720-012-363 Seal, U-Cup Shaft 4
34 722-094-600 Seat, Check Valve 4
722-094-150 Seat, Check Valve (see item 27 must use 8) 4
722-094-110 Seat, Check Valve (see item 27 must use 8) 4
35 920-025-000 Ground Strap 1
36 900-004-330 5/16 Lock Washer (Alum) 48
900-004-330 5/16 Lock Washer (SS) 32
Parts not shown used with Raised Face ANSI Flange Options R and W:
170.043.330 Hex Cap Screw 4
326.054.080 Mounting Foot 2
545.003.330 Hex Nut 4
900.001.330 Lock Washer 4
901.035.330 Flat Washer 8
Parts not shown used with Raised Face ANSI Flange Option R ONLY:
334.122.110 1/2" ANSI 150# Raised Face Flange and
Threaded Pipe Connection 2
538.006.110 1/2" NPT Pipe Nipple x 1 1/2 Long 2
MODEL SPECIFIC
3: EXP
VIEW
