SANDPIPER S1F Non-Metallic - Manual (Page 4)

s1fnmdl3sm-rev0614
1: PUMP
SPECS
sandpiperpump
.
com
1
• Model S1F Non-Metallic
Explanation of Pump Nomenclature
ATEX Detail
Non-Wetted Material Options
P Polypropylene
1 40% Glass Filled Polypropylene
with PTFE hardware
C Conductive Polypropylene
Porting Options
N NPT Thread
U Universal (Fits ANSI and DIN)
7 Dual Porting (ANSI)
8 Top Dual Porting (ANSI)
9 Bottom Dual Porting (ANSI)
Pump Style
D With Electronic Leak
Detection (110 V)
E With Electronic Leak
Detection (220V)
I Inline Porting NPT Threads
M With Mechanical
Leak Detection
S Standard
V With Visual Leak Detection
Pump Options
0 None
1 Sound Dampening Muffler
2 Mesh Muffler
3 Expanded Clearance Air Valve
w/Integral Muffler
4 Expanded Clearance Air Valve
w/Sound Dampening Muffler
5 Expanded Clearance Air Valve
w/Mesh Muffler
6 Metal Muffler
7 Metal Muffler with Grounding
Cable
Pump Brand
S SANDPIPER ®
Pump Size
1F 1" Full Flow
Check Valve Type
B Ball
Design Level
3 Design Level
Wetted Material
K PVDF
P Polypropylene
C Conductive Polypropylene
V Conductive PVDF
Diaphragm/Check Valve Materials
1 Santoprene/Santoprene
2 PTFE Santoprene Backup/PTFE
3 PTFE Pumping, PTFE-Santoprene
Backup Driver/PTFE
4 Santoprene Pumping/Santoprene
B Nitrile/Nitrile
G PTFE-Neoprene Backup/PTFE
M Santoprene/PTFE
N Neoprene/Neoprene
V FKM/FKM
Y PTFE Pumping/One-Piece Bonded
Driver/PTFE
Z One-Piece Bonded/PTFE
Check Valve Seat
K PVDF
P Polypropylene
A1. Solenoid Kit with 12 VDC
ATEX Compliant Coil
A2. Solenoid Kit with 24 VDC
ATEX Compliant Coil
A3. Solenoid Kit with 110/120 VAC
50/60 Hz ATEX Compliant Coil
A4. Solenoid Kit with 220/240 VAC
50/60 Hz ATEX Compliant Coil
Kit Options
00. None
P0. 10.30VDC Pulse Output Kit
P1. Intrinsically-Safe 5.30VDC,
110/120VAC 220/240 VAC
Pulse Output Kit
P2. 110/120 or 220/240VAC
Pulse Output Kit
E0. Solenoid Kit with 24VDC Coil
E1. Solenoid Kit with 24VDC
Explosion-Proof Coil
E2. Solenoid Kit with 24VAC/12VDC Coil
E3. Solenoid Kit with 12VDC
Explosion-Proof Coil
E4. Solenoid Kit with 110VAC Coil
E5. Solenoid Kit with 110VAC
Explosion-Proof Coil
E6. Solenoid Kit with 220VAC Coil
E7. Solenoid Kit with 220VAC
Explosion-Proof Coil
E8. Solenoid Kit with 110VAC, 50 Hz
Explosion-Proof Coil
E9. Solenoid Kit with 230VAC, 50 Hz
Explosion-Proof Coil
SP. Stroke Indicator Pins
Your Serial #: (fill in from pump nameplate) _____________________________________
Pump Pump Check Design Wetted Diaphragm/ Check Valve Non-Wetted Porting Pump Pump Kit
Brand Size Valve Level Material Check Valve Seat Material Options Style Options Options
S XX X X X X X X X X X XX Model #:
S __ ____ __ __ __ __ __ __ __ __ __ ____
(fill in from pump
nameplate)
Your Model #:
IEC EEX m T4
Note: Pump models equipped with these explosion-proof
solenoid kit options E1, E3, E5, E7, E8 or E9, are certified
and approved by the above agencies.
They are NOT ATEX compliant.
(4)
Note: Pumps are only ATEX compliant when ordered with
wetted material option C or V, non-wetted material option
C, pump option 0, 6 or 7, and kit option 0.
II 2GD T5
(1) II 1G c T5
II 3/1 G c T5
II 1D c T100°C
I M1 c
I M2 c
Note: Pumps ordered with the options listed in (1) to the
left are ATEX compliant when ordered with kit option P1.
II 2G Ex ia c IIC T5
II 2D c iaD 20 IP67 T100˚C
(2)
II 2G Ex ia c IIC T5
II 3/2 G Ex ia c IIC T5
II 2D Ex c ia 20 IP67 T100°C
Note: Pumps ordered with the options listed in (1) to the left
are ATEX compliant when ordered with kit option A1, A2,
A3, or A4. Compressed Air Temperature Range: Maximum Ambient
Temperature to plus 50°C.
II 2G EEx m c T5
II 2D c IP65 T100°C
(3)
*Note: See Special Conditions For Safe Use.
II 2G EEx m c II T5
II 3/2 2G EEx m c II T5
II 2D c IP65 T100°C
MODEL SPECIFIC
