• Model S15 Non-Metallic
Explanation of Pump Nomenclature
ATEX Detail
Non-Wetted Material Options
C Carbon Filled Conductive
Polypropylene
P 40%Glass Filled Polypropylene
1 40%Glass Filled Polypropylene
w/PTFE Coated Hardware
Porting Options
A ANSI Flange
D DIN Flange
7 Dual Porting (ANSI)
8 Top Dual Porting (ANSI)
9 Bottom Dual Porting (ANSI)
Pump Style
D with Electronic Leak Detection (110V)
E with Electronic Leak Detection (220V)
M with Mechanical Leak Detection
S Standard
V with Visual Leak Detection
Pump Options
0 None
1 Sound Dampening Muffler
2 Mesh Muffler
3 High temperature Air Valve
w/Integral Muffler
4 High temperature Air Valve
w/Sound Dampening Muffler
5 High temperature Air Valve
w/Mesh Muffler
6 Metal Muffler
7 Metal Muffler w/ Grounding Cable
Pump Brand
S SANDPIPER ®
Pump Size
15 1 1/2"
Check Valve Type
B Ball
Design Level
3 Design Level
Wetted Material
K PVDF
P Polypropylene
C Conductive Polypropylene
Diaphragm/Check Valve Materials
1 Santoprene/Santoprene
2 PTFE-Santoprene Backup/PTFE
6 PTFE Pumping, PTFE-Neoprene
Backup Driver/PTFE
B Nitrile/Nitrile
C FKM / PTFE
G PTFE-Neoprene Backup/PTFE
M Santoprene/PTFE
N Neoprene/Neoprene
U Urethane/Urethane
Z One-Piece Bonded/PTFE
Check Valve Seat
K PVDF
P Polypropylene
A1. Solenoid Kit with 12 VDC
ATEX Compliant Coil
A2. Solenoid Kit with 24 VDC
ATEX Compliant Coil
A3. Solenoid Kit with 110/120 VAC
50/60 Hz ATEX Compliant Coil
A4. Solenoid Kit with 220/240 VAC
50/60 Hz ATEX Compliant Coil
Kit Options
00. None
P0. 10.30VDC Pulse Output Kit
P1. Intrinsically-Safe 5.30VDC,
110/120VAC 220/240 VAC
Pulse Output Kit
P2. 110/120 or 220/240VAC
Pulse Output Kit
E0. Solenoid Kit with 24VDC Coil
E1. Solenoid Kit with 24VDC
Explosion-Proof Coil
E2. Solenoid Kit with 24VAC/12VDC Coil
E3. Solenoid Kit with 12VDC
Explosion-Proof Coil
E4. Solenoid Kit with 110VAC Coil
E5. Solenoid Kit with 110VAC
Explosion-Proof Coil
E6. Solenoid Kit with 220VAC Coil
E7. Solenoid Kit with 220VAC
Explosion-Proof Coil
E8. Solenoid Kit with 110VAC, 50 Hz
Explosion-Proof Coil
E9. Solenoid Kit with 230VAC, 50 Hz
Explosion-Proof Coil
SP. Stroke Indicator Pins
Your Serial #: (fill in from pump nameplate) _____________________________________
Pump Pump Check Design Wetted Diaphragm/ Check Valve Non-Wetted Porting Pump Pump Kit
Brand Size Valve Level Material Check Valve Seat Material Options Style Options Options
S XX X X X X X X X X X XX Model #:
S __ ____ __ __ __ __ __ __ __ __ __ ____
(fill in from pump
nameplate)
Your Model #:
IEC EEX m T4
Note: Pump models equipped with these explosion-proof
solenoid kit options E1, E3, E5, E7, E8 or E9, are certified
and approved by the above agencies. They are NOT ATEX
compliant.
(4)
Note: Pumps are only ATEX compliant when ordered with
wetted material option C, non-wetted material option C,
pump option 0, 6 or 7, and kit option 0.
II 2GD T5
(1)
II 1G c T5
II 3/1 G c T5
II 1D c T100°C
I M1 c
I M2 c
Note: Pumps ordered with the options listed in (1) to the
left are ATEX compliant when ordered with kit option P1.
II 2G Ex ia c IIC T5
II 2D c iaD 20 IP67 T100˚C
(2) II 2G Ex ia c IIC T5
II 3/2 G Ex ia c IIC T5
II 2D Ex c ia 20 IP67 T100°C
*Note: See Special Conditions For Safe Use.
Note: Pumps ordered with the options listed in (1) to the left are
