SANDPIPER S15 Non-Metallic - Manual (Page 11)

s15nmdl3sm-rev0614
sandpiperpump
.
com Model S15 Non-Metallic •
8
ATEX Compliant
Composite Repair Parts List
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
16 286-119-600 Diaphragm, Overlay 2
17 312-101-520 Elbow, Discharge 2
312-101-552 Elbow, Discharge 2
312-101-557 Elbow, Discharge 2
18 312-115-520 Elbow, Suction 2
312-115-552 Elbow, Suction 2
312-115-557 Elbow, Suction 2
19 360-093-360 Gasket, Main Air Valve 1
20 360-103-360 Gasket, Pilot Valve 2
21 360-104-360 Gasket, Air Inlet Cap 1
360-104-379 Gasket, Air Inlet Cap
(Conductive Models Only) 1
22 360-107-360 Gasket, Inner Chamber 2
23 518-197-520 Manifold 2
518-197-520E Manifold, 40mm DIN 2
518-197-552 Manifold 2
518-197-552E Manifold, 40mm DIN 2
518-197-557 Manifold 2
518-197-557E Manifold, 40mm DIN 2
24 545-008-110 Nut, Hex 1/2-13 32
545-008-308 Nut, Hex 1/2-13 32
25 560-001-360 O-Ring 2
26 612-195-157 Inner, Plate Diaphragm 2
612-227-150 Inner Diaphragm Plate
(One-Piece Bonded Option) 2
27 612-225-520 Outer, Plate Diaphragm 2
612-225-552 Outer, Plate Diaphragm 2
28 620-004-114 Plunger, Actuator 2
29 670-045-520 Retainer, Ball 4
670-045-552 Retainer, Ball 4
30 675-042-115 Ring, Retainer 2
31 685-063-120 Rod, Diaphragm 1
32 720-004-360 Seal, U-Cup 2
33 720-035-600 Seal, Check Valve Assembly 8
34 720-037-600 Seal, Manifold 4
35 722-074-520 Seat, Check Valve 4
722-074-552 Seat, Check Valve 4
36 901-038-115 Washer, Flat 5/16" 4
901-038-308 Washer, Flat 5/16" 4
37 901-046-115 Washer, Flat 1/2" 96
901-046-308 Washer, Flat 1/2" 96
38 901-048-115 Washer, Flat 3/8" 4
901-048-308 Washer, Flat 3/8" 4
NOT SHOWN:
535-010-000 Muffler 1
530-027-000 Muffler 1
530-033-000 Muffler 1
Item Part Number Description Qty
1 031-140-000 Air Valve Assembly 1
031-140-001 Air Valve Assembly 1
031-140-002 Air Valve Assembly
w/ PTFE coated Hardware 1
031-141-000 Air Valve Assembly
(No Integral Muffler) 1
031-141-001 Air Valve Assembly
(No Integral Muffler) 1
031-141-002 Air Valve Assembly
(No Integral Muffler 1
PTFE Coated Hardware)
2 095-110-558 Pilot Valve Assembly 1
3 050-036-354 Ball, Check 4
050-036-357 Ball, Check 4
050-036-360 Ball, Check 4
050-036-365 Ball, Check 4
050-036-600 Ball, Check 4
4 114-024-551 Intermediate Assembly 1
114-024-559 Intermediate Assembly 1
5 132-035-360 Bumper, Diaphragm 2
6 135-034-506 Bushing, Plunger 2
7 165-118-551 Air Inlet Cap Assembly 1
165-118-559 Air Inlet Cap Assembly 1
8 170-055-115 Capscrew, Hex HD
1/2-13 x 2.50 32
170-055-308 Capscrew, Hex HD
1/2-13 x 2.50 32
9 170-069-115 Capscrew, Hex HD
5/16-18 x 1.75 4
170-069-308 Capscrew, Hex HD
5/16-18 x 1.75 4
10 170-092-115 Capscrew, Hex HD
1/2-13 x 4.00 16
170-092-308 Capscrew, Hex HD
1/2-13 x 4.00 16
11 171-053-115 Capscrew, Soc HD
3/8-16 x 2.75 4
171-053-308 Capscrew, Soc HD
3/8-16 x 2.75 4
12 171-078-115 Capscrew, Flat HD
3/8-16 x1.25 8
13 196-187-520 Chamber, Outer 2
196-187-552 Chamber, Outer 2
196-187-557 Chamber, Outer 2
14 196-188-551 Chamber, Inner 2
196-188-559 Chamber, Inner 2
15 286-005-354 Diaphragm 2
286-005-357 Diaphragm 2
286-005-360 Diaphragm 2
286-005-363 Diaphragm 2
286-005-365 Diaphragm 2
286-114-000 Diaphragm,
One-Piece Bonded PTFE 2
Item Part Number Description Qty
MODEL SPECIFIC
3: EXP
VIEW
