st15dl4sm-rev0614 Models ST1½, ST40 Page 14
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 070-006-170 Bearing, Sleeve 2
2 114-002-156 Bracket, Intermediate 1
114-002-010 Bracket, Intermediate 1
3 720-004-360 Seal, U-Cup 2
4 135-008-000 Bushing, Threaded (with O-Ring) 2
5 620-004-114 Plunger, Actuator 2
6 095-073-000 Pilot Valve Body Ass’y. 1 1
6-A 095-070-551 Pilot Valve Body 1
6-B 755-025-000 Sleeve (with O-Ring) 1
6-C 560-033-360 O-Ring (Sleeve) 4
6-D 775-026-000 Spool (with O-Ring) 1
6-E 560-023-360 O-Ring (Spool) 2
6-F 675-037-080 Retaining Ring 1
7 360-041-379 Gasket, Valve Body 1
8 560-001-360 O-Ring (Sold with Item 4) 2
9 530-036-000 Muffler, Exhaust 1
10 095-043-156 Body, Valve 1
095-043-010 Body, Valve 1
11 132-014-358 Bumper, Valve Spool 2
12 165-066-010 End Cap Assembly 2
13 360-048-425 Gasket, Valve Body 1
14 360-010-425 Gasket, End Cap 2
15 560-020-360 O-Ring 6
16 031-066-000 Sleeve & Spool Set 1
17 170-032-115 Capscrew, Hex Hd., 1/4-20 Size 8
18 170-045-115 Capscrew, Hex Hd., 5/16-18 Size 4
19 132-002-360 Bumper, Diaphragm Plate 2
20 560-022-360 O-Ring 2
21 685-007-120 Rod, Diaphragm 1
22 196-029-156 Chamber, Inner Diaphragm 2
196-029-015 Chamber, Inner Diaphragm 2
23-1 115-062-080 Bracket, Foot, Left Hand 2
23-2 115-062-080 Bracket, Foot, Right Hand 2
24 612-052-157 Plate, Inner Diaphragm 2
612-052-010 Plate, Inner Diaphragm 2
25 612-096-110 Plate, Outer Diaphragm 2
26 170-024-115 Capscrew, Hex Hd., 7/16-14 Size 8
27 900-006-115 Washer, Lock 7/16 Size 48
28 618-007-115 Plug, Pipe 1 NPT Size 2
29 286-005-365 Diaphragm 2
286-005-364 Diaphragm 2
286-005-363 Diaphragm 2
30 902-003-000 Stat-O Seal 2
31 196-028-156 Chamber, Driver 2
196-028-010 Chamber, Driver 2
32 807-033-115 Stud 7/16-14 Size 16
34 545-007-115 Nut, Hex 7/16-14 Size 40
35 170-058-115 Capscrew, Hex Hd. 7/16-14 Size 4
36 170-060-115 Capscrew, Hex Hd. 7/16-14 Size 20
37 618-003-110 Plug, Pipe 1/4 NPT Size 4
38 560-043-360 O-Ring 2
560-043-363 O-Ring 2
560-043-364 O-Ring 2
39 807-017-115 Stud 7/16-14 Size 4
40 170-006-330 Capscrew, Hex Hd., 3/8-16 Size 4
Repair Parts shown in bold face
(darker) type are more likely to need
replacement after extended periods
of normal use. They are readily
available from most Warren Rupp
distributors. The pump owner may
prefer to maintain a limited inven-
tory of these parts in his own stock
to reduce repair downtime to a
minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number,
serial number and type number.
1 Available only in kit form. Order Kit 031-055-000 which also includes items 5 ,7, 13 and 60.
Model ST1½ Type 4
Model ST40 Type 4
SERVICE & OPERATING MANUAL
Original Instructions
II 2GD T5
See pages 18 & 19
for ATEX ratings
