Fig 2.8 Alarm status
Alarm output:
The DVR has 4-channel relay alarm output, which just give on/off signal to external alarm. The status of these pin are
illustrated as 2.8.
N O
. .
COM
N C
. .
N O
. .
COM
N C
. .
Before alarm
After alarm
Fig 2.9 Relay Output Status
Users need connect their alarm according to the NO or NC type of the alarm. One connection example as Fig 2.1
