59
Digital Video Recorder User Manual
Step 3: After acquiring the IP address, Subnet Mask and so on, please enter into the DVR’s Main MenuSetupNetwork
interface to manually input IP address, Subnet Mask and Gateway according to the configuration of PC. The network
segment should be the same as the PC. If using DHCP, please enable DHCP in the DVR and router.
Step 4: After finishing the above information, users can enter LAN IP and http port in the Safari browser. For example: input
http://192.168.1.100:81(here 192.168.1.100 is LAN IP of DVR, 81 is the http port of DVR). Click “
”button, the browser
will download Active X control as shown below:
Step 5: Click icon and then select the Active X control, the welcome interface will be shown. Click
“Continue””Install” button，the following window will pop up：
