SAE400 & SAE400 WELD’N AIR
F-4 DIMENSION PRINT F-4
18.50
22.14
22.00
27.12 24.50
8.12
3.00
.88
43.75
63.06
39.69
50.13
28.00
32.87
6.00
81.25
69.75
77.00
39.38
44.50
8.90
83.00
* = .81 DIA HOLES = .69 DIA HOLES
*
*
CENTER OF GRAVITY WITH OIL AND WATER IN ENGINE, BUT NO FUEL.
