A-1 INSTALLATION
SAE400 & SAE400 WELD ’ N AIR
A-1
TECHNICAL SPECIFICATIONS - SAE400 & SAE400 WELD ’ N AIR
Make/Model Description Speed (RPM) Displacement Starting Capacities
System
Perkins 4 cylinder High Idle 1800 256 cu. in 12VDC batteries Fuel: 22.5 gal.
1004.42 Diesel 71 HP @ Low Idle 1100 (4.2 L) (2) & Starter 85.1 L
Engine 1725 RPM Full Load 1725
Bore x Stroke Oil: 8.5 Qts.
8.04 L
3.875” x 5.00”
(98.4 mm x 127.0mm) Coolant: 3.6 gal.
13.63 L
INPUT - DIESEL ENGINE
RATED OUTPUT - WELDER
HEIGHT WIDTH DEPTH WEIGHT
50.13 in. 28.00 in. 83.00 in. SAE400 2125 lbs.
963.9 kg
1273.3 mm 711.2 mm 2108.2 mm SAE400 2428 lbs.
WELD’N AIR 1101.3 kg
OUTPUT - WELDER AND GENERATOR
AIR COMPRESSOR OUTPUT - SAE400 WELD ’ N AIR ONLY
Duty Cycle (1) Welding Output Volts at Rated Amps
60% (NEMA) 400 amps 36 volts
60% (Lincoln Plus) 400 amps 40 volts
Welding Range Open Circuit Voltage Auxiliary Power
80 - 575 Amps 97 Max. OCV 115/230 VAC
@ 1800 RPM 3000 Watts, 60 Hz.
100% Duty Cycle
Make/Model Description Delivery Tank Capacity & Rating Operating Pressure Oil Capacity
IMT 4-cylinder 35 CFM 11 Gallons Loads at 90 P.S.I. 1.33 Quarts
(Iowa Mold Reciprocating, at 100 P.S.I. (41.6 Liters) (6.3 kg/cm 2 ) (1.26 Liters)
Tooling/ Diamond Water Cooled, at 60% Maximum Allowable Unloads at 130 P.S.I. IMT’s
Air) Pressure Lubricated Duty Cycle (1) Working Pressure (9.1 kg/cm 2 ) Synthetic
Aluminum Alloy 991 Liters/min. 150 PSI Compressor
Model Block with Cast- at 7.0 kg/cm 2 (10.5 kg/cm 2 ) Oil
DA435ELW Iron sleeves
PHYSICAL DIMENSIONS
(1) Based on a 10 minute period.
