C-1 ACCESSORIES C-1
K930-2 Hi-Freq ™ - Provides high frequency plus a
gas valve for TIG welding. A water valve is available as
an option. Requires 115 volt AC input. (Limited to 250A
- 60% Duty Cycle).
K802-D Power Plug Kit - Kit includes male plugs for
each auxiliary receptacle.
K767-1 Trailer - A 4-wheel steerable trailer for in-plant
and yard towing (1) with E78-14 load range (B) tubeless
tires. Mounts directly to welder base.
K956-1Trailer - A 2-wheel trailer designed for road (1) ,
off road, in-plant and yard towing. Trailer mounts
directly to welder base.
1 For highway use, consult applicable federal, state and local laws regarding
possible requirements for brakes, lights, fenders, etc.
Pipe Thawing with an arc welder can cause fire,
explosion, damage to electric wiring or to the arc
welder if done improperly. The use of an arc
welder for pipe thawing is not approved by the
CSA, nor is it recommended or supported by
Lincoln Electric.
------------------------------------------------------------------------
K704 Standard Accessory Kit - Includes electrode
and work cables, headshield, work clamp and elec-
trode holder.
K385-1 CV Adapter - Provides constant voltage output
for semiautomatic welding. (Field installation only).
K2144-1 Oil Drain Kit - Includes ball valve, hose and
clamp.
K1847-1 Spark Arrestor Kit
K1690-1 GFCI RECEPTACLE KIT
Includes one UL approved 120V ground fault circuit
interrupter duplex type receptacle with cover and
installation instructions. Replaces the factory installed
120V duplex receptacle. Each receptacle of the GFCI
Duplex is rated at 20 Amps, the maximum total current
from the GFCI Duplex is limited to the 20 Amps. Two
kits are required.
K2303-1 SHEET METAL KIT- For SAE400 model
K1278-5.
SAE400 & SAE400 WELD ’ N AIR
WARNING
