Connection diagram – Lincoln Electric IM799 POWER WAVE F355i(CE) User Manual
Page 32
F-3
CONNECTION DIAGRAM
F-3
POWER WAVE F355i (CE)
Connection Diagram Semi-automatic "Simple System"
(Electrode Positive, CV / Pulse Configuration shown)
SEE SECTION A-4, Power Wave / Power Feed Wire
Feeder Interconnections
POWER WAVE F355i
COMMUNICATION INTERFACE
OPTIONAL (K2436-1)
NOT ON CODES 10997 OR BELOW.
VOLTAGE SENSE LEADS
(OPTIONAL) K940
FANUC R-J3i
WIRE
FEEDER
CONTROL CABLE K1785
TO
WORK
