SEMIAUTOMATIC PW450 FULL VOLTAGE CALIBRATION USING A WELDING ARC (continued)
CALIBRATION
– POLARITY (+21A)
+ POLARITY
– POLARITY
NOTE: Do not attempt to weld for –Polarity
(+21A). Set the number to the same as
recorded for +Polarity (+67A). Also for
+Polarity and –Polarity, move the volt-
meter sense lead from the conductor
block of the wire feeder to the positive
output terminal on the front of the
machine.
9. Turn the machine off. Connect the
Synergic 7 to the Wire feeder 2 amphenol
on the back of the Power Wave machine.
10. Put the voltmeter sense lead back on the
wire feeder conductor block and repeat
the calibration process steps 5, 6, and 7
for the following test points:
+POLARITY (+67B)
–POLARITY (+21B)
NOTE: Do not attempt to weld for –Polarity
(+21B). Set the number to the same as
recorded for +Polarity (+67B).
