A-1 INSTALLATION
POWER WAVE 455M/STT (CE)
A-1
TECHNICAL SPECIFICATIONS - POWER WAVE 455M/STT (CE) (K2203-4)
OUTPUT
RECOMMENDED INPUT WIRE AND FUSE SIZES
PHYSICAL DIMENSIONS
TEMPERATURE RANGES
INPUT AT RATED OUTPUT - THREE PHASE ONLY
INPUT
VOLTS
380V - 60Hz.
380V - 50Hz.
415V - 60Hz.
415V - 50Hz.
OPEN
CIRCUIT
VOLTAGE
75 VDC
INPUT
VOLTAGE /
FREQUENCY
380V Hz.
415V Hz.
HEIGHT
663 mm
(26.10 in)
WIDTH
505 mm
(19.86 in)
DEPTH
835 mm
(32.88 in)
WEIGHT
121 kg.
(267 lbs.)
TYPE 75°C
(SUPER LAG)
OR BREAKER
SIZE (AMPS)
40 A
40 A
TYPE 75°C
GROUND WIRE
IN CONDUIT
AWG[IEC] SIZES
(mm 2 )
10 (6)
10 (6)
TYPE 75°C
COPPER WIRE
IN CONDUIT
AWG[IEC] SIZES
(mm 2 )
8 (10)
8 (10)
INPUT AMPERE
RATING ON
NAMEPLATE
36 A
33 A
DUTY
CYCLE
100%
100%
MIG/MAG
FCAW
SMAW
Pulse
STT
50-500 A
40-500 A
30-500 A
5-750 A
40-325 A
PULSE
VOLTAGE
RANGE
5 - 55 VDC
AUXILIARY
POWER
40 VDC AT
10 AMPS
220 VAC AT
5 AMPS
PULSE AND
BACKGROUND
TIME RANGE
100 MICRO SEC.
-
3.3 SEC.
STT PARAMETERS
PEAK & BACK-
GROUND CURRENT
15-450 AMPS
CURRENT
RANGE
AMPS
5 - 570 A
PULSE
FREQUENCY
0.15 - 1000 Hz
INPUT
CURRENT
AMPS
36 A
36 A
33 A
33 A
INPUT
CURRENT
AMPS
48 A
48 A
44 A
44 A
OUTPUT CONDITIONS
AMPS / VOLTS / DUTY CYCLE
EXCEPT STT PROCESS
400A@36V. 100%
400A@36V. 100%
400A@36V. 100%
400A@36V. 100%
STT PROCESS ALL VOLTAGES
325A@33V. 100%
OUTPUT CONDITIONS
AMPS / VOLTS / DUTY CYCLE
EXCEPT STT PROCESS
500A@40V. 60%
500A@40V. 60%
500A@40V. 60%
500A@40V. 60%
STT PROCESS ALL VOLTAGES
325A@33V. 100%
OPERATING TEMPERATURE RANGE
-20°C to 40°C
STORAGE TEMPERATURE RANGE
-40°C to 40°C
PROCESS CURRENT RANGE (DC) CURRENT AMPS
