Recommended Spare Parts are Highlighted in Bold
1 Remote Switch S23283-1 1 X
2 Switch Enclosure S23283-2 1 X
3 Control Board, Work Lamp S23283-3 1 X
4 Control Leads, Work Lamp S23283-4 1 X
5 Housing, Work Lamp S23283-5 1 X
6 Plastic Lens Cap S23283-8 2 X
7 Halogen Lamp S23283-6 1 X
8 Glass Spatter Guard S23283-10 1 X
9 Holding Spring S23283-9 1 X
10 Fuse Holder, 20A S23284-1 1 X
11 Fuse, 2.5A/250V, Slow-blow S23284-2 1 X
12 Connection Block S23284-6 1 X
13 Transformer, 115/24V, 48VA S23284-4 1 X
14 Contactor, 24V/60Hz, 10VA S23151-1 1 X
15 Thermal Relay, 8-12.5A S23272 1 X
16 Lamp Kit Cable, 36 ft. (11m) S23270-2 1 X
3-4-98
LAMP KITS
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-322-D.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-322-D.1
