ACCESSORIES
INVERTEC RACKS
- 9 -
OPTIONAL FIELD INSTALLATION
ACCESSORIES
Options are available on all racks unless otherwise
specified.
K905-1 115V Power Pack
K906-1 Caster Wheel Kit*
K907-1 Quick Connect Plug Kit
K908-1 50 Ft. Primary Cord Extension
* Available on K898 series of aluminum racks (4) only.
K905-1 115V Power Pack
If not purchased already installed, a 115V power pack
is available as a field installed option. The 115V power
pack consist of a step-down transformer delivering
1KVA (10 amps) of power through a weather proof
GFI duplex receptacle. This supplemental power
source is useful for powering additional tools and
equipment.
K906-1 Caster Wheel Kit
K906-1 caster wheel kit is a field installed option.
Caster wheels offer mobility for convenient in-shop
use. K906-1 is available for K898 series of aluminum
racks (4) only.
K907-1 Quick Connect Plug Kit
K907-1 quick connect plugs are a field installed
option. The kit comes with fur sets of quick connect
plugs which makes power source-to-rack power con-
nection quick and easy for four power sources. Two
kits are needed for a steel rack (8). A power source
can be disconnected from the rack for relocation with-
out interrupting the productivity of other operators.
Receptacles mount and hang by a short line cord from
underneath the fuse box. Each mating plug mounts to
a power source line cord. The quick connect plugs
are 3 pole/4 wire plugs, weather sealed for outdoor
use, and mate with a twist lock action.
K908-1 50 ft. Primary Cord Extension
K908-1 is a 50 ft. line cord terminated at each end
with a quick connect to be used in conjunction with
K907-1 quick connect plug kit. K908-1 allows a power
source to be relocated around the job site and still
draw power from one central location.
K943-1 Invertec Mounting Bracket Kit
K934-1 is a field installed option. This kit allows up to
four Invertec V250S machines to be mounted into any
K898 or K912 series of racks.
Weights
Model Type Weight
K905-1 115V Power Pack 31 lbs / 14.0 kg
K906-1 Caster Wheel Kit 13 lbs / 5.9 kg
K907-1 Quick Connect Plug Kit 14 lbs / 6.4 kg
K908-1 50 ft. Primary Cord Extension 24 lbs / 10.9 kg
K934-1 Invertec Rack Mounting 4.5 lbs / 2.1 kg
Bracket Kit
Electrical
K905-1 115V Power Pack
K905-1 115 v power pack provides 1KVA (10 amps)
of auxiliary power and is protected by a 10A circuit
breaker. The power pack is powered by the same
main power supply source that feeds the rack, there-
fore, reconnection of the power pack may be neces-
sary depending on the input voltage applied. When
factory installed, K905-1 is connected for the highest
available input voltage connection. See rack wiring
diagram for reconnection.
K907-1 Quick Connect Plug Kit
Maximum ratings for quick connects are 600V @ 50
amps of service. Fuse power sources for 50A maxi-
mum for low voltage operation when using quick con-
nect plugs.
