Page 11

Press the key , the digit in this position increases to a maximum

of 9.

Press the key , the digit in this position decreases to a minimum

of 0.

Press the key a sixth time to repeat setting steps. When all the

digits are determined, press the key to enter the X-direction
grade setting.

Y-direction SLOPE Setting
Press the key to switch digital positions, the operation is the

same as the X-direction “SLOPE” setting.

Note:
Before pressing the key only five keys for grade setting

and the power key are enabled. The other

keys are disabled.

After pressing the key the “SLOPE” display on the LCD will flash.

While flashing all the keys are disabled except the power key.

Backlight
Press and hold the key for 2 seconds, the backlight on the

keypad can be turned on and off.

Remote Control Function
Most operations of the laser 40-6580

can be controlled by the remote
control.

40-6747
