Chapter 1
2
VX900-I USER MANUAL
CPU
Specifications
• VIA ® VX900(Colay VX900H) Chipset Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports DDR3 1066 MHz DDR3 SDRAM
Memory
• 1 x PCI slot
• Supported by VIA ® VX900(Colay VX900H) Express Chipset
- 2 x Serial ATA 3Gb/s devices
- RAID 1.0 configuration
Expansion Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-Sub port (VGA)
• 1 x COM port
• 1 x HDMI port
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (1x Line out, 1x Mic_in Rear)
Rear Panel I/O
LAN • Realtek 8111E Gigabit Lan(Co-lay 8105E)
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
Realtek 8105E
- 10/100 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Onboard VIA ® Single Core L2007 1.6G(colay Dual Core 4300/
4350) processor
• Supports FSB 800/533/400 MHz
• 25W
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 3-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 2 x Serial ATA 3Gb/s connectors
• 2 x COM headers
• 1 x LVDS connector (optional)
• 1 x Case open header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x Parallel port header (LPT)
• 1 x CLR_CMOS header
• 1 x Front panel USB power select jumper
• 1 x Rear USB/PS2 power select jumper
Internal I/O
Connectors &
Headers
• VIA VT1705CE
-
6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
